CA61(2)50普通车床[国标]



型号 Model
CA6240
CA6250
CA6161
CA6261
CA6166
CA6266
CA6180
CA6280
床身上最大工件直径
Max. Swing over bed
400mm
500mm
610mm
660mm
800mm
刀架上最大工件直径
Max. Swing over carriage
210mm
300mm
370mm
400mm
540mm
马鞍槽最大工件直径
Max. Swing in gap
-
630mm
-
720mm
-
830mm
-
880mm
-
1020mm
马鞍槽有效长度
Effective gap length
-
210mm
-
210mm
-
210mm
-
210mm
-
210mm
最大工件长度
Max. Length of  workpiece
750mm or 1000mm or 1500mm or 2000mm or 3000mm
床身宽度 Width of bed
400mm
刀杆截面 Section of turning tool
25X25mm
主轴 Spindle
主轴转速范围
Spindle speeds
11—1600 r/min (24 steps)
主轴内孔
Hole though spindle
52mm(80mm)
主轴孔锥度
Spindle taper
Morse No.6 (莫氏6号)
进给 Feed
进给数量 No. of feeds
64种(kinds)(for each)
公制螺纹Range of metric threads (kinds)
(1-192mm)44种(44kinds)
英制螺纹 Range of inch threads(kinds)
(1-24tpi)21种(21kinds)
模数螺纹 Rage of module threads(kinds)
0.25-48(模数39种)(Module 39 kinds)
径节螺纹 Rage of Diametral pitc threads (kinds)
1-96DP(37种)(37 kinds)
床尾 Tailstock
床尾主轴最大行程
Max tailstock spindle travel
150mm
床尾主轴直径 Tailstock spindle diameter
75mm
床尾主轴孔锥度
Morse No.5 (莫氏5号)
主电机 Main motor
7.5KW(10HP)
包装外形尺寸
Picking dimensions
(L×M×H mm)
Overall dimensions for 750
2440X1150X1170
2440X1150X1700
2440X1190X1700
2440X1150X1900
2440X1150X1950
Overall dimensions for 1000
2650X1150X1700
2650X1150X1700
2650X1190X1700
2650X1150X1900
2650X1150X1950
Overall dimensions for 1500
3150X1150X1700
3150X1150X1700
3150X1190X1700
3150X1150X1900
3150X1150X1950
Overall dimensions for 2000
3610X1150X1700
3610X1150X1700
3610X1190X1700
3650X1150X1900
3650X1150X1950
Overall dimensions for 3000
4610X1150X1700
4610X1150X1700
4610X1190X1700
4650X1150X1900
4650X1150X1950
重量
Weight
(Kg)
Length
毛重 G.W.   净重 N.W.
Overall dimensions for 750
2700     2000
2700     2000
2860     2260
2900     2300
3000     2400
Overall dimensions for 1000
2800     2100
2700     2000
3050     2450
3060     2460
3200     2600
Overall dimensions for 1500
3050     2250
2700     2000
3240     2640
3250     2650
3400     2800
Overall dimensions for 2000
3300     2600
2700     2000
3480     2880
3480     2880
3500     3000
Overall dimensions for 3000
4000     3450
2700     2000
4287     3687
4300     3700
4500     3900



 备注:

1.马鞍车床在普通车床上加2000元,轻型马鞍车床在轻型普通车床上加1000元。

 2.B型车床Φ80孔径的在普通车床Φ52孔径的基础上加3000元,C型车床Φ105孔径的在普通车床Φ52孔径的基础上加12000元。

3.CA6140普通车床无C型Φ105孔径配置。

4.特殊偏远地区另加运费1000元。
